CHAPTER 4 APPLIED OPERATION
E5CK
4–1
CHAPTER 4
APPLIED OPERATION
This chapter describes each of the parameters required for making full
use of the features of the E5CKĆT.
Read this chapter while referring to the parameter descriptions in chapĆ
ter 5.
CHAPTER4
4.1 Selecting the Control Method 4Ć2. . . . . . . . . . . .
Heating and cooling control 4Ć2. . . . . . . . . . . . .
ON/OFF control 4Ć4. . . . . . . . . . . . . . . . . . . . . . .
4.2 Operating Condition Restrictions 4Ć5. . . . . . . .
Manipulated variable restrictions 4Ć5. . . . . . . .
Set point limiter 4Ć6. . . . . . . . . . . . . . . . . . . . . . .
4.3 Ramp Rise Rate Setup Program 4Ć7. . . . . . . . .
Running the ramp rise rate setup program 4Ć8
Program example 4Ć9. . . . . . . . . . . . . . . . . . . . . .
4.4 Program Operation 4Ć10. . . . . . . . . . . . . . . . . . . .
Hold/Advance 4Ć10. . . . . . . . . . . . . . . . . . . . . . . . . .
Pattern operation 4Ć11. . . . . . . . . . . . . . . . . . . . . .
4.5 Program output 4Ć13. . . . . . . . . . . . . . . . . . . . . . . .
Time signal 4Ć13. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Program output 4Ć14. . . . . . . . . . . . . . . . . . . . . . . .
4.6 Setting Running Conditions 4Ć15. . . . . . . . . . . . .
Operation at power ON 4Ć15. . . . . . . . . . . . . . . . .
Starting the program run 4Ć16. . . . . . . . . . . . . . .
End condition 4Ć16. . . . . . . . . . . . . . . . . . . . . . . . .
4.7 How to Use Event Input 4Ć17. . . . . . . . . . . . . . . .
Input assignments 4Ć17. . . . . . . . . . . . . . . . . . . . .
Detailed description of input functions 4Ć18. . .
4.8 LBA 4Ć19. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.9 How to Use Transfer Output 4Ć21. . . . . . . . . . . .
