Omron E5CK User Manual

CHAPTER 5 PARAMETERS
E5CK
5–46
Communication stop bit
Communication data length
Communication parity
Communication baud rate
Communication unit No.
Conditions of Use
The communications function must be in
use.
Ă• These parameters are enabled when the power is turned ON again.
Ă• These parameters set the communications conditions. Make sure that the stop bit,
data length, parity and baud rate of the host computer and the E5CKĆT controller are
matching.
Ă• When connecting two or more E5CKĆT controllers to the host computer, set unit Nos.
that will not conflict with the unit Nos. of other controllers.
Ă• Communication stop bit" parameter
Setting Range
Unit Default
1, 2 Bits 2
Ă• Communication data length" parameter
Setting Range
Unit Default
7, 8 Bits 7
Ă• Communication parity" parameter
Setting
Default
“ ”: None/ “ ”:Even/“ ”:Odd
Ă• Communication baud rate" parameter
Setting Range
Unit Default
1.2, 2.4, 4.8, 9.6, 19.2 kbps 9.6
Ă• Communication unit No." parameter
Setting Range
Unit Default
0 to 99 None 0
ĂRelated description
Chapter 6 Using the Communications Functions
ĂRelated parameter
Remote/Local" (level 2 mode)
ĂOption units
E53ĆCK01/03
Option Mode
Function
Setting
See
Model
