Omron E5CK User Manual

E5CK
5–19
Cooling coefficient
Conditions of Use
The control must be either heating and
cooling control, or advanced PID control.
Ă• In heating and cooling control, P at the cooling side is calculated by the following forĆ
mula:
Cooling side P = Cooling coefficient x P
Setting Range Unit Default
0.01 to 99.99 None 1.00
ĂRelated description
4.1 Selecting the Control Method/Heating and cooling control (page 4Ć2)
ĂRelated parameter
Proportional band" (level 1 mode)
Dead band
Conditions of Use
The control system must be heating and
cooling control.
Ă• Sets the output dead band width in a heating and cooling control system. A negative
setting sets an overlap band.
Setting Range Unit Default
-19.99 to 99.99 %FS 0.00
ĂRelated description
4.1 Selecting the Control Method/Heating and cooling control (page 4Ć2)
Level 1 Mode
Function
Setting
See
Function
Setting
See

Omron E5CK Specifications

General

Ambient Operating Temperature	-10 to 55°C
Protection Rating	IP20
Control Type	PID
Input Type	Thermocouple, RTD
Output Type	Relay, Voltage, Current
Power Supply Voltage	100 to 240 VAC
Mounting Type	Panel
Display Type	Digital
Control Output	Relay, Voltage, Current
Alarm Output	Relay
Dimensions	48 x 48 x 78 mm
Ambient Operating Humidity	25% to 85% RH
