APPENDIX
E5CK
A–2
SPECIFICATIONS
JRatings
Supply voltage
100 to 240V AC, 50/60 Hz 24 VAC/DC, 50/60 Hz
Operating Voltage
Range
85% to 110% of rated supply voltage
Power Consumption 15VA 6 VA, 3.5 W
Sensor Input
Thermocouple: K, J, T, E, L, U, N, R, S, B, W, PLII *1, *2
Platinum resistance thermometer: JPt100, Pt100
Voltage input: 4 to 20 mA, 0 to 20 mA (input impedance 150Ω)
Current input: 1 to 5 V, 0 to 5 V, 0 to 10 V (input impedance 1MΩ)
Control Output According to output unit (see “Output Unit Ratings and Characteristics” (page A-4)
Auxiliary Output SPST-NO, 3 A at 250 VAC (resistive load)
Control Method Advanced PID or ON/OFF control
Setting Method Digital setting using front panel keys.
Indication Method 7-segment digital display and LEDs
Other Functions According to option unit (see “Option Unit Ratings and Characteristics” (page A-4)
Ambient Temperature -10°C to 55°C (without condensation and icing)/3-year warranty period: -10 to 50°C
Ambient Humidity 35% to 85% (relative humidity)
Storage Temperature -25°C to 65°C (without condensation and icing)
*1 Thermocouple W is W/Re5Ć26.
*2 For the setting ranges and indication ranges for each of inputs, see page AĆ4.
*1,
*2
