APPENDIX
E5CK
A–4
JSensor Input Setting Ranges and Indication Ranges
Input Setting Range Indication Range
JPt100 -199.9 to 650.0 (C°) / -199.9 to 999.9 (F°) -199.9 to 735.0 (C°) / -199.9 to 999.9 (F°)
Pt100 -199.9 to 650.0 (C°) / -199.9 to 999.9 (F°) -199.9 to 735.0 (C°) / -199.9 to 999.9 (F°)
K1 -200 to 1300 (C°) / -300 to 2300 (F°) -350 to 1450 (C°) / -560 to 2560 (F°)
K2 -0.0 to 500.0 (C°) / -0.0 to 900.0 (F°) -50.0 to 550.0 (C°) / -90.0 to 990.0 (F°)
J1 -100 to 850 (C°) / -100 to 1500 (F°) -195 to 945 (C°) / -260 to 1660 (F°)
J2 -0.0 to 400.0 (C°) / -0.0 to 750.0 (F°) -40.0 to 440.0 (C°) / -75.0 to 825.0 (F°)
T -199.9 to 400.0 (C°) / -199.9 to 700.0 (F°) -199.9 to 460.0 (C°) / -199.9 to 790.0 (F°)
E 0 to 600 (C°) / -0 to 1100 (F°) -60 to 660.0 (C°) / -110 to 1210 (F°)
L1 -100 to 850 (C°) / -100 to 1500 (F°) -195 to 945 (C°) / -260 to 1660 (F°)
L2 0.0 to 400.0 (C°) / 0.0 to 750.0 (F°) -40.0 to 440.0 (C°) / -75.0 to 825.0 (F°)
U -199.9 to 400.0 (C°) / -199.9 to 700.0 (F°) -199.9 to 650.0 (C°) / -199.9 to 999.9 (F°)
N -200.0 to 1300 (C°) / -300 to 2300 (F°) -199.9 to 460.0 (C°) / -199.9 to 790.0 (F°)
R 0 to 1700 (C°) / 0 to 3000 (F°) -350 to 1450 (C°) / -560 to 2560 (F°)
S 0 to 1700 (C°) / 0 to 3000 (F°) -170 to 1870 (C°) / -300 to 3300 (F°)
B 100 to 1800 (C°) / 300 to 3200 (F°) -170 to 1870 (C°) / -300 to 3300 (F°)
W 0 to 2300 (C°) / 0 to 4100 (F°) -70 to 1970 (C°) / 10 to 3490 (F°)
PLII 0 to 1300 (C°) / 0 to 2300 (F°) -230 to 2530 (C°) / -410 to 4510 (F°)
4 to 20mA
0 to 20mA
1 to 5V
0 to 5V
0 to 10V
One of following ranges depending on
results of scaling
-1999 to 9999
-199.9 to 999.9
-19.99 to 99.99
-1.999 to 9.999
-10 to 110% of setting range.
Note, however, that max. value is -1999
to 9999.
JOutput Unit Ratings and Characteristics
Ratings and characteristics conform to the output unit mounted on the
controller. For details on the ratings of the output unit, see page 2Ć7.
JOption Unit Ratings and Characteristics
Contact input ON: 1kΩ max., OFF: 100kΩ min.
Event inputs
No-contact input
ON: residual voltage 1.5 V max., OFF: leakage current 0.1 mA
max.
Communications
Interface :RS-232C, RS-422 or RS-485
Transmission method :Half-duplex
Synchronization method :Start-stop synchronization (asynchronous method)
Baud rate :1.2/2.4/4.8/9.6/19.2 kbps
Transfer output
DC 4 to 20 mA, Permissible load impedance: 600Ω max., Resolution: Approx.
2600
