CHAPTER 3 BASIC OPERATION
E5CK
3–6
In this example, let's check the input type and temperature units, and shift
the lower limit by 1C and the upper limit by 3C.
input type" = 2: K1"
temperature unit" = C"
input shift upper limit"= 3.0"
input shift lower limit" = 1.0"
(1) Select the menu display, and select ăă : setup mode" using the
or keys. For details on selecting the menu display, see page
1Ć10.
(2) Press the
key for one second minimum to enter the setup mode.
The top parameter in the setup mode 
: input type" is displayed.
This parameter is factoryĆset to 2: K1".
(3) Press the
key to fix the set value. The display changes to ăă :
C/F selection" parameter. This parameter is factoryĆset to 
: C".
(4) Select the menu display, and select 
: level 2 mode" using the
or keys.
(5) Press the
key for one second minimum to enter the level 2 mode.
The top parameter in the level 2 mode [ăă
] (local/remote" paĆ
rameter) is displayed.
(6) Press the
key until [ ] (input shift upper limit" parameter)
is selected. This parameter is factoryĆset to 0.0".
(7) Press the
key until 3.0" is displayed.
(8) Press the
key until [ ] (input shift lower limit" parameter)
is selected. This parameter is factoryĆset to 0.0".
(9) Press the
key until 1.0" is displayed. This sets the input shift
upper limit" and input shift lower limit" values.
Setting Example
1 second min.
1 second min.
1 second min.
