4 Configuring Measurement Settings
4 - 12
Vision System FH Series Operation Manual for Sysmac Studio (Z343)
This allows you to control the measurement of the image. Refer to Image control section on page 2-19.
This allows you to enlarge or reduce the displayed image.
The place where the image is displayed in the left zoom area is enclosed in a rectangle.
You can move the display place by moving this rectangle.
Image control section
Image size control section
Button Description
Enlarges the image. Doubles the size of displayed image. (Upper limit: 1600%)
Reduces the image. Halves the size of displayed Image. (Lower limit: 1%)
Makes the image to fit the display frame.
The zoom ratio can be specified by directly entering a numerical value or by moving the
slider.

Omron fh series Specifications

General

Type	Machine Vision System
Series	FH Series
Power Supply	24 VDC
Storage Temperature	-20 to 60°C
Humidity	35 to 85% RH (non-condensing)
Image Sensor	CMOS
Processing Speed	High-speed processing
Connectivity	Ethernet
I/O	Digital I/O
Operating System	Embedded OS
I/O Ports	Ethernet, USB
