Omron SYSMAC C200HS - Page 165

Appendix BSpecifications
151
Circuit Configuration
Output indicator
F indicator
OUT00
OUT07
COM
CN1
OUT08
OUT15
COM
Internal
Circuit
4.5 to
26.4 VDC
4.5 to
26.4 VDC
Fuse
CN1
CN2
SW
OUT00
OUT07
COM
CN2
OUT08
OUT15
COM
Internal
Circuit
4.5 to
26.4 VDC
4.5 to
26.4 VDC
Fuse
Indicator
switch/
fuse
blowout
detection
circuit
Maximum Switching Capacity
Power Supply Voltage (V)
Max. Switching Capacity (mA/pt) Max. Switching Capacity (A/unit)
Ambient Temperature (°C)
0 4.5 10 20.4 26.4
50
100
16
0
0 10203040505560
0
1.0
2.0
3.0
4.0
5.0
6.0
6.4
