For connection of camera cables, refer to the following table.
3-3-4 Cable Connection Table
Camera Cable for FH-S Camera Series
Name
Model of
Sensor
Controller
Length
High-speed digital CMOS Camera (Standalone)
0.3
megapixel
camera
2 megapixel camera 4 megapixel camera
FH-SM/SC FH-SM02/SC02 FH-SM04/SC04
--- High speed Standard High speed Standard
Camera cable
Right-angle Camera
cable
FZ-VS3
FZ-VSL3
2 m
    
3 m
    
5 m
    
10 m
 ×  × 
Bend resistant Camera
cable
Bend resistant
R
ight-angle Camera
cable
FZ-VSB3
FZ-VSLB3
2 m
    
3 m
    
5 m
    
10 m
 ×  × 
Long-distance Camera
cable
Long-distance
R
ight-angle Camera
cable
FZ-VS4
FZ-VSL4
15 m
 ×  × 
Name
Model of
Sensor
Controller
Length
High-speed digital CMOS Camera (Stand-
alone)
Digital CMOS Camera
12 megapixel camera 5 megapixel camera
FH-SM12/SC12 FH-SC05R/SM05R
High speed Standard ---
Camera cable
Right-angle Camera
cable
FZ-VS3
FZ-VSL3
2 m
  
3 m
  
5 m
  
10 m
×  
Bend resistant Camera
cable
Bend resistant
R
ight-angle Camera
cable
FZ-VSB3
FZ-VSLB3
2 m
  
3 m
  
5 m
  
10 m
×  
Long-distance Camera
cable
Long-distance
R
ight-angle Camera
cable
FZ-VS4
FZ-VSL4
15 m
×  
