5 - 5
5 Setup and Wiring
Vision System FH/FZ5 series Hardware Setup Manual (Z366)
5-1 When turning ON and OFF
5
5-1-2 FH-1000/FH-3000 Series
• Re-confirm the followings before turning ON the power.
• Is the correct voltage and polarity of the power (ENC0_VDD/GND ENC1_VDD/GND)
which supplies to encoder cable (DC5)?
• Re-check the ground wire before turning ON the power.
• Confirm the following before turning ON.
• Is the voltage and polarity of the power source set correctly?
(DC24V for positive terminal. D
C0V for negative terminal.)
• Make sure to connect the earth (FG) only to the grounding terminal.
Precautions for Correct Use
RESET signal
Do not input RESET immediately after turning ON the power. If you want to use RESET input to
synchronize with the timing of startup, turn ON the RESET signal 15 seconds after turning ON
the power of the Sensor Controller.
Do not touch the fluorescent light or halogen lamp while in operation, or immediately after turn-
ing OFF the power.
Precautions for Correct Use
RESET signal
Do not input RESET immediately after turning ON the power. If you want to use RESET input to
synchronize with the timing of startup, turn ON the RESET signal 15 seconds after turning ON
the power of the Sensor Controller.
5-1-2 FH-1000/FH-3000 Series
5-1-3 FH-L Series
5-1-4 FZ5 Series
5-1-5 FZ5-L Series
