2-1 Overview of System
An FH/FZ5 series Sensor Controller uses pre-built packages that contain all the processing tasks (for
image input, measurement processing, displays, outputs, etc.) that are required for vision inspections.
You arrange these packaged processes in order of execution of the vision inspection.
An FH/FZ5 series Sensor Controller executes visio
n inspections according to user-created flows.
Additional Information
In the FH/FZ5 series Sensor Controller, a flow that contains packaged processes that are
arranged in order of execution of processing items and image processing is called a measure
-
ment flow.
Processing items and measurement flows can have
more than one setting. You can switch the
setting based on the scene to inspect. (Refer to the Vision System FH/FZ5 series User's Man-
ual (C
at. No. Z365).)
