Omron SYSMAC FH Series Hardware Setup Manual

1 - 3
1 Confirm the Package
Vision System FH/FZ5 series Hardware Setup Manual (Z366)
1-1 Sensor Controller
1
1-1-3 FH-1-20 / FH-3-20 Series
• Sensor Controller: 1
FH-1-
20 or FH-3-20: 1
• Instruction Sheet (Japanese and English): 1
• Instruction Installation Man
ual for FH series: 1
• General Compliance Information and Instructions for EU: 1
• Power source: 1(male)
FH-XCN: 1
• Ferrite core for camera cable: 8
• Sensor Controller: 1
FH-L: 1
• Instruction Sheet (Japanese and English): 1
• Instruction Installation M
anual for FH-L series: 1
• General Compliance Information and Instructions for EU: 1
• Power source: 1 (male)
FH-XCN-L: 1
1-1-3 FH-1-20 / FH-3-20 Series
1-1-4 FH-L Series
