5 Setup and Wiring
5 - 28
Vision System FH/FZ5 series Hardware Setup Manual (Z366)
5-4
Setup Touch Panel Monitor or Monitor
Describes the notifications of Sensor Controller when you setup Touch Panel Monitor or Monitor.
For handling or functions of monitor, r
efer to each of instruction sheet.
• Use only the cables designed specifically for the product. Use of other products may result in
malfunction or damage of the product.
• Always turn OFF the power of the Sensor Controller and peripheral devices before connect-
ing or disconnecting a camera or cable. Connecting the cable with power supplied may result
in
damage of the camera or peripheral devices.
• Do not apply torsion stress to the cable. It may damage the cable.
• Secure the minimum bending radius of the ca
ble. Otherwise the cable may be damaged.
• Please insert DVI-I connector perpendicularly so that the connector resin part and pin are not
rubbing against each other. Damaged pin may cause contact failure due to generation and
invasion of resin powder.
• When you connect FH-1000 series or FH-3000 series to the FH-MT12 via USB cable:
Do not ground the positive terminal of DC24V power source. The internal circuit is possible to
b
e given damage, it can be cause the failure.
Precautions for Correct Use
When connect the Sensor Controller and monitor with a switcher and splitter
Do not use devices that make the Sensor Controller recognize the monitor again when switch-
ing operation is performed. Re-recog
nition process in switching operation has an effect such as
a delay in measurement time.
When fix the DVI connector
If difficult to fix the bilateral screws of DVI connector
, once loosen these. Then retry to fix, again.
5-4-1 All Series
5-4-2 FH-1000/FH-3000 Series
