Omron SYSMAC FH Series Hardware Setup Manual

5 - 33
5 Setup and Wiring
Vision System FH/FZ5 series Hardware Setup Manual (Z366)
5-5 Camera Installation
5
5-5-5 FZ5-L Series
Precautions for Safe Use
Ground
When the connected camera to the Sensor Control comes packaged with a base, make sure to
mount with the base.
Since the enclosure of the camera main
body made of metals is short-circuited with the internal
circuit, the internal circuit might be short-circuited with FG if no base is used, so that failures or
malfunctions may be caused.
5-5-5 FZ5-L Series
