1 Confirm the Package
Vision System FH/FZ5 series Hardware Setup Manual (Z366)
1-2 Sold Separately
1
1-2-4 Accessories
1-2-4 Accessories
Appearance Description Model Reference
USB Memory 2 GB FZ-MEM2G
8 GB FZ-MEM8G
SD memory card
2 GB
HMC-SD291
4 GB
HMC-SD491
USB/Monitor Switcher FZ-DU
---
Mouse
Driverless wired mouse
(A mouse that requires the mouse driver
to be installed is not supported.)
---
EtherCAT junction
sl
aves
3 port Power supply voltage:
DC20.4V to DC28.8V
(DC24V-15% to +20%)
Current consump-
tion: 0.22 A
GX-JC03
6 port Current consump-
tion: 0.22 A
GX-JC06
Industrial Switching
Hu
bs for EtherNet/IP
and Ethernet
3 port Failure detection: None Current consump-
tion: 0.22 A
W4S1-03B
5 port Failure detection: None Current consump-
tion: 0.22 A
W4S1-05B
Failure detection:
Supported
W4S1-05C
--- Calibration Plate FZD-CAL
Common items
relate
d to DIN rail
(for FH-L550/-L550-10)
DIN rail mounting bracket
FH-XDM-L
DIN
35mm
ra
il
PHOENIX CONTACT • Length:
75.5/95.5/115.5/2
00 cm
• Height: 7.5mm
• Material: Iron
•Surface:
Conductive
NS 35/7,5
PERF
• Length:75.5/95.5/
115.5/200 cm
• Height: 15mm
• Material: Iron
•Surface
Conductive
NS 35/15
PERF
End
plate
Need 2 pieces each
Sensor
Controller
CLIPFIX 35
