*1. Do not use the 0.5-mm, 1.0-mm, and 2.0-mm Extension Tubes attached to each other. Since these Extension Tubes are
placed over the threaded section of the Lens or other Extension Tube, the connection may loosen when more than one
0.5-mm, 1.0-mm or 2.0-mm Extension Tube are used together.
Reinforcement is required to protect against vibration when
Extension Tubes exceeding 30 mm are used.
When using the Extension Tube, check it on
the actual device before using it.
3-4-8 Extension Tubes
Specification
Lenses
For M42 mount Lenses
*1
For C mount Lenses
*1
For Small Digital CCD Cameras
Model 3Z4S-LE VS-EXR/M42 3Z4S-LE SV-EXR FZ-LESR
Contents Set of 5 tubes (20 mm, 10 mm, 8
mm, 2 mm, and 1 mm)
Maximum outer diameter: 47.5
mm di
a.
Set of 7 tubes (40 mm, 20 mm,10
mm, 5 mm, 2.0 mm, 1.0 mm, and
0.5 mm)
Maximum outer diameter: 30 mm
di
a.
Set of 3 tubes (15 mm,10 mm, 5
mm)
Maximum outer diameter: 12 mm
di
a.
