3 - 59
3 Configuration
Vision System FH/FZ5 series Hardware Setup Manual (Z366)
3-4 Lens
3
3-4-7 High-resolution Telecentric Lens for C-mount Lens for 2/3-inch Image Sensor
*1. Insert the shape into  in the model number as follows.
Straight: -O
Coaxial: CO-O
*2. The working distance is the distance from the
end of the lens to the sensor.
*3. The depth of field is calculated using a permissib
le circle of confusion diameter of 0.04 mm.
*4. The resolution is calculated using a wavelength of 550 nm.
Note 1. Fixing the lens or other reinforcement may be required depending on the installation angle or operating
environment (vibration/shock).
When fixing the lens, insulate the lens from the fixture.
2. The above specifications are value
s calculated from the optical design and can vary depending on
installation conditions.
Model
*1
3Z4S-LE
VS-TCH4
-65
3Z4S-LE
VS-TCH4
-110
Optical magnification (±5%) 4.0 ×
Field of
view
(±5%)
(V × H)
(mm)
FH-SC/-SM 1/3 inch equiva-
lent
1.2 × 0.9
FH-S05R 1/2.5 inch equiva-
lent
1.43 × 1.
07
FZ-SC/-S 1/3 inch equiva-
lent
1.2 × 0.9
FZ-SC2M/-S2M 1/1.8 inch equiva-
lent
1.8 × 1.3
FZ-SC5M/-S5M 2/3 inch equiva-
lent
2.1 × 1.8
WD (mm)
*2
65 110.8
Effective FNO 17.91 22.2
Depth of field (mm)
*3
0.09 0.11
Resolution (μm)
*4
3 3.73
TV distortion 0.02% 0.03%
Maximum sensor size 2/3 inch
