3 Configuration
Vision System FH/FZ5 series Hardware Setup Manual (Z366)
3-2 Camera
3
3-2-5 Small Digital CCD Cameras: FZ-S Camera Series
3-2-5 Small Digital CCD Cameras: FZ-S Camera Series
Specification
Model FZ-SF FZ-SFC FZ-SP FZ-SPC
Image elements Interline transfer reading all pixels, CCD image
elements (1/3-inch equivalent)
Color/Monochrome Monochrome Color Monochrome Color
Effective pixels 640 (H) × 480 (V)
Imaging area H × V
(opposing corner)
4.8 × 3.6 (6.0 mm)
Pixel size 7.4 (μm) × 7.4 (μm)
Shutter function Electronic shutter; select shutter speeds from 20 μm to
100 ms
Partial function 12 to 480 lines
Frame rate
(Image Acquisition
Ti
me)
80 fps (12.5 ms)
Lens mounting Special mount (M10.5 P0.5)
Field of vision, instal-
lation distance
Selecting a lens according to the field of vision and installation distance
Ambient temperature
range
Operating of camera amp: 0 to 50°C
Operating of camera head: 0 to 45°C
Storage: -25 to 65°C (with no icing or condensation)
Ambient humidity
ra
nge
Operating and storage: 35 to 85%RH (with no condensation)
Minimum bending
ra
dius between cam-
era head and camera
amplifie
r
12.7mm
Weight Approx. 150 g
Accessories Instruction Sheet, inst
allation bracket,
Four mounting brackets (M2 × 4)
Instruction Sheet
