5 - 29
5 Setup and Wiring
Vision System FH/FZ5 series Hardware Setup Manual (Z366)
5-4 Setup Touch Panel Monitor or Monitor
5
5-4-3 FH-L Series
• Please insert monitor connector perpendicularly so that the connector resin part and pin are
not rubbing against each other. Damaged pin may cause contact failure due to generation
and invasion of resin powder.
• When you connect FH-L series to the FH-MT12 via USB cable:
Do not ground the positive terminal of DC24V power
source. The internal circuit is possible to
be given damage, it can be cause the failure.
Precautions for Correct Use
When connecting the sensor controller and monitor with a switcher and splitter
Do not use devices that make the Sensor Controller recognize the monitor again when switch-
ing operation is performed. Re-recognition process in switchin
g operation has an effect such as
a delay in measurement time.
When fix the DVI connector
If difficult to fix the bilateral screws of DVI connector
, once loosen these. Then retry to fix, again.
Please insert monitor connector perpendicularly so that the connector resin part and pin are not
rubbing against each other. Damaged pin may cause contact failure due to generation and
invasion of resin powder.
Please insert monitor connector perpendicularly so that the connector resin part and pin are not
rubbing against each other. Damaged pin may cause contact failure due to generation and
invasion of resin powder.
5-4-3 FH-L Series
5-4-4 FZ5 Series
5-4-5 FZ5-L Series
