6 I/O Interface
Vision System FH/FZ5 series Hardware Setup Manual (Z366)
6-1 Parallel Interface
6
6-1-4 NPN Input/Output for FZ5 Series
Parallel interface differs the appropriated Sensor Controller depending on NPN output and PNP output.
Parallel interface is NPN/PNP in common. An appropriate wiring is required according on the external
device.
Encoder interface (open corrector type) is also included.
Encoder interface (open corrector type) is ENC
TRIG_A0, ENCTRIG_B0, and ENCTRIG_Z0
Wire the pins to Encoder appropriately.
 NPN I/O type
• Camera 2ch type: FZ5-1200/FZ5-1100/FZ5-800/FZ5-600
• Camera 4ch type: FZ5-1200-10/FZ5-1100-10/FZ5-800-10/FZ5-600-10
• Specifications differ by number of pins
• Encoder interface (open corrector type) is ENCTRIG_A
0 (B2pin), ENCTRIG_B0 (B3pin), and ENC-
TRIG_Z0 (B4 pin). The frequency response of Encode
r interface (open corrector type) is 0.95 KHz.
 [Input]
Applicable signals/
RESET, DI0 to DI7, DSA0, DSA1
6-1-4 NPN Input/Output for FZ5 Series
Interface Specification
Item Specifications
Input voltage 12 to 24 VDC ±10%
ON current
*1
*1. ON current and ON voltage:
Those mean the current or voltage to turn ON from OFF. The ON voltage value is the potential difference
between COMIN and each input terminal.
5 mA min.
ON voltage
*1
8.8 V min.
OFF current
*2
*2. OFF current and OFF voltage:
Those mean the current or voltage to turn OFF from ON. The OFF voltage value is the potential difference
between COMIN and each input terminal.
0.5 mA max.
OFF voltage
*2
1.1 V max.
ON delay 5 ms max.
OFF delay 0.7 ms max.
