Omron SYSMAC FH Series

5 Setup and Wiring
5 - 14
Vision System FH/FZ5 series Hardware Setup Manual (Z366)
The power source connected to the FH-L series Sensor Controller changes the power consumption
depending on the number of camera. Refer to the following table.
When you connect the camera using lighting Controller
, the power consumption is same when connect
to the Intelligent Compact Digital Camera.
Recommended Power Source for FH-L Series
Item Camera Type Number of Camera FH-L FH-L-
Recommended
Power Source
S8VK-G
S8VS
Intelligent Compact
Digital Camera
2 S8VK-G12024
S8VS-09024
S8VK-G112024
S8VS-09024
4
---
S8VK-G12024
S8VS-12024
Camera of
0.3/2/4/5/12 milli
on
pixels
2 S8VK-G-06024
S8VS-06024
S8VK-G-06024
S8VS-06024
4
---
S8VK-G-06024
S8VS-06024
