5 Setup and Wiring
5 - 52
Vision System FH/FZ5 series Hardware Setup Manual (Z366)
Note Fix without removing the insulation leg because neither the ventilation route is closed nor the case are con-
nected with FG.
Installation in a Control Panel
51
4-M4 depth 6.5 Insulation leg
100
5910.5
