6 I/O Interface
6 - 48
Vision System FH/FZ5 series Hardware Setup Manual (Z366)
Wring
Connect both ends of the cable shield with the connector hood.
Use the T568A wiring method as mentioned above.
Pin Layout
Pin assignment Pin No. Signal name Abbreviation Signal direction
1 Transmission data + TD + Out
2 Transmission data - TD - Out
3 Reception data + RD + In
4 Not connected NC ---
5 Not connected NC ---
6 Reception data - RD - In
7 Not connected NC ---
8 Not connected NC ---
Connector hood Security ground FG ---
Pin No.
1
2
3
4
5
6
7
8
Connector hood
Pin No.
1
2
3
4
5
6
7
8
Connector hood
Wire color
White·Green
Green
White·Orange
Blue
White·Blue
Orange
White·Brown
Brown
Shielded cable
Wire color
White·Green
Green
White·Orange
Blue
White·Blue
Orange
White·Brown
Brown
Shielded cable
