Omron SYSMAC FH Series Hardware Setup Manual

6 - 53
6 I/O Interface
Vision System FH/FZ5 series Hardware Setup Manual (Z366)
6-4 Ethernet Interface
6
6-4-2 FH-L Series
Describes the connection processing to connector hood of shield as the following. The connection pro-
cessing is changed accordin
g to the transfer speed.
• 10BASE-T/100BASE-TX
Connects the shield of its both ends to each of connector
hoods. Connects the shield of only one side
of switching hub to connector hoods.
• 1000BASE-T
Connects the shield of its both ends to each of connector hoods.
Wiring
