Omron SYSMAC FH Series Hardware Setup Manual

6 I/O Interface
6 - 56
Vision System FH/FZ5 series Hardware Setup Manual (Z366)
Describes the connection processing to connector hood of shield as the following. The connection pro-
cessing is changed according to the transfer speed.
• 10BASE-T/100BASE-TX
Connects the shields of both its ends to each of the conn
ector hoods. Connects the shield of only one
side of switching hub to connector hoods.
• 1000BASE-T
Connects the shield of both its ends to each of the connector hoods.
Wire
