Omron SYSMAC FH Series Hardware Setup Manual

3 Configuration
3 - 4
Vision System FH/FZ5 series Hardware Setup Manual (Z366)
*1. When the 12 megapixels camera: Max. 4 cameras are connectable.
When use except 12 megapixels cameras:
Max. 8 cameras are connectable.
*2. Existing third class grounding
Current
co
nsump-
tion
When con-
nected to a
Co
ntroller
Connected to
2 cameras
5.0 A max. 5.4 A max. 6.4 A max. 4.7 A max. 5.0 A max. 5.9 A max.
Connected to
4 cameras
---
7.0 A max. 8.1 A max.
---
6.5 A max. 7.5 A max.
Connected to
8 cameras
--- ---
11.5 A
max.
--- ---
10.9 A
ma
x.
When not
con
nected
to Control-
ler
Connected to
2 cameras
4.1 A max. 4.2 A max. 5.2 A max. 3.6 A max. 3.7 A max. 4.5 A max.
Connected to
4 cameras
---
4.8 A max. 5.6 A max.
---
4.3 A max. 5.0 A max.
Connected to
8 cameras
--- ---
6.8 A max.
--- ---
6.2 A max.
Built-in FAN Yes
Usage
Env
iron-
ment
Ambient temperature
range
Operating: 0°C to 50°C
Storage: -20 to +65°C (with no icing or condensation)
Ambient humidity range Operating:35 to 85%RH
Storage: 35 to 85%RH (with no condensation)
Ambient atmosphere No corrosive gases
Vibration tolerance Oscillation frequency: 10 to 150 Hz
Half amplitude: 0.1 mm
Acceleration: 15 m/s
2
Sweep time: 8 minute/count
Sweep count: 10
Vibration direction: up and down/front
an
d behind/left and right
Oscillation frequency: 10 to 150 Hz
Half amplitude: 0.1 mm
Acceleration: 15 m/s
2
Sweep time: 8 minute/count
Sweep count: 10
Vibration direction: up and down/front
and be
hind/left and right
Shock resistance
Impact force: 150 m/s
2
Test direction: up and down/front and
behind/left and right
Impact force: 150 m/s
2
Test direction: up and down/front and
behind/left and right
Noise
immunity
Fast Tran-
sient Burst
• DC power
Direct infusion: 2kV, Pulse rising: 5ns, Pulse width: 50ns,
Burst continuation time: 15ms/0.75ms, Perio
d: 300ms, Application time: 1 min
• I/O line
Direct infusion: 1kV, Pulse rising: 5ns, Pulse width: 50ns,
Burst continuation time: 15ms/0.75ms, Perio
d: 300ms, Application time: 1 min
Grounding
Type D grounding (100Ω o
r less grounding resistance)
*2
External
Features
Dimensions 190 mm × 115 mm × 182.5 mm
Note Height: Including the rubber feet at the base.
Weight Approx.
3.2 kg
Approx.
3.4 kg
Approx.
3.4 kg
Approx.
3.2 kg
Approx.
3.4 kg
Approx.
3.4 kg
Degree of protection IEC60529 IP20
Case material Cover: zinc-plated steel plate
Side plate: aluminum (A6063)
Sensor Controller Series FH-3000 series FH-1000 series
Type High-speed Controller (4 cores) Standard Controller (2 cores)
Sensor Controller Model FH-3050 FH-3050-10 FH-3050-20 FH-1050 FH-1050-10 FH-1050-20
