3 Configuration
3 - 14
Vision System FH/FZ5 series Hardware Setup Manual (Z366)
*1. This can be increased up to 1024 using the Scene group conversion tool.
*2. Existing third class grounding
Current
co
nsump-
tion
When con-
nected to a
Controll
er
Connected to 2 cameras 5.0 A max. 7.5 A max.
Connected to 4 cameras ---
Connected to 8 cameras --- ---
When not
connected
to Controller
Connected to 2 cameras 3.7 A max. 4.9 A max.
Connected to 4 cameras ---
Connected to 8 cameras ---
Built-in FAN Yes
Usage Envi-
ronment
Ambient temperature range Operating: 0°C to 45°C
(When the Built-in FAN is set to slow rotation.)
Operating: 0°C to 50°C
(When the Built-in FAN is set to fast rotation.)
Storage: -20 to +65°C
Ambient humidity range Operating and Storage: 35 to 8
5%RH (with no condensation)
Ambient atmosphere No corrosive gases
Vibration tolerance Oscillation frequency: 10 to 150 Hz
Half amplitude: 0.1 mm
Acceleration:15 m/s
2
Sweep time: 8 minute/count
Sweep count: 10 times
Vibration direction: up and down/front and behind/left and right
Shock resistance
Impact force: 150 m/s
2
Test direction: up and down/front and behind/left and right
Noise
immu
nity
Fast Transient Burst • DC power
Direct infusion: 2kV, Pulse rising: 5ns, Pulse width: 50ns,
Burst continuation time: 15ms, Peri
od: 300ms, Application
time: 1 min.
• I/O line
Direct infusion: 1kV, Pulse rising: 5ns, Pulse width: 50ns,
Burst continuation time: 15ms/0.75ms, Period: 300ms, Appli-
cation time: 1 min
Grounding
Type D grounding (100Ω o
r less grounding resistance)
*2
External
Features
Dimensions 260 mm × 308 mm × 83 mm 260 mm × 308 mm × 104 mm
Weight Approx. 3.2 kg Approx. 3.4 kg
Degree of protection IEC60529 IP20
Case material
ABS
Sensor Controller Series FZ5-1200 series
Type High-speed Controller
Sensor Controller Model FZ5-1200 FZ5-1205 FZ5-1200-10 FZ5-1205-10
