Omron SYSMAC FH Series

3 - 19
3 Configuration
Vision System FH/FZ5 series Hardware Setup Manual (Z366)
3-1 Sensor Controller
3
3-1-3 FZ5-600/FZ5-800/FZ5-1100/FZ5-1200 Series
 FZ5-600 Series
Sensor Controller Series FZ5-600 series
Type Standard Controller
Sensor Controller Model FZ5-600 FZ5-605 FZ5-600-10 FZ5-605-10
Controller Type Liquid Crystal Display type
Parallel IO NPN PNP NPN PNP
Main Func-
tions
Operation
Mode
Standard Yes
Double Speed Multi-input Yes
Non-stop adjustment mode Yes
Multi-line random-trigger
mo
de
No
Parallel Processing No
Number of Connectable Camera 2 4
Supported
Camera
FH-S series camera Not connectable
FZ-S series camera All of the FZ-S series cameras are connectable.
(When the 5 megapixel camera is connected, the maximum
conn
ectable camera is 2.)
Camera I/F OMRON I/F
Possible Number of Captured Images Refer to About Number of Logging Images or About Max. Num-
ber of Loading Images during Multi-input i
n the Vision System
FH/FZ5 series User's Manual (Cat. No. Z365).
Possible Number of Logging Images to
Se
nsor Controller
Possible Number of Scenes 128
Operating
on UI
USB Mouse Yes (wired USB driver-less type)
Touch Panel No (RS-232C/USB connection: FH-MT12)
Setup Create the processing flow using Flow editing.
Language Japanese, English, Simplified Chinese, Traditional Chinese
External
Interf
ace
Serial Communication RS-232C/422 × 1
Ethernet
Co
mmuni-
cation
Protocol Non-procedure (TCP/UDP)
I/F 100BASE-TX × 1
EtherNet/IP Communication Ethernet port (transmission rate: 100 Mbps)
EtherCAT Communication No
Parallel I/O • 13 inputs/26 outputs
Encoder Interface None
Monitor Interface Analog RGB video output × 1 for maintenance
USB I/F USB2.0 host × 4 (BUS Power: Port 5V)
SD Card I/F None
Indicator
La
mps
Main POWER: Green
ERROR: Red
RUN: Yellow
Ethernet NET RUN: Green
NET LINK ACT: Yellow
SD Card None
EtherCAT None
Power-supply voltage 20.4 VDC to 26.4 VDC
Current
co
nsump-
tion
When con-
nected to a
C
ontroller
Connected to 2 cameras 5.0 A max. 7.5 A max.
Connected to 4 cameras ---
Connected to 8 cameras ---
When not
connected
to Controller
Connected to 2 cameras 3.7 A max. 4.9 A max.
Connected to 4 cameras ---
Connected to 8 cameras ---
Built-in FAN Yes
