Omron SYSMAC FH Series Hardware Setup Manual

3 - 29
3 Configuration
Vision System FH/FZ5 series Hardware Setup Manual (Z366)
3-2 Camera
3
3-2-1 High-speed digital CMOS Camera (FH-S camera series)
 0.3 Megapixels Camera: FH-SC/-SM
 2 Megapixels Camera: FH-SC02/-SM02 and
4 Megapixels Camera: FH-SC04/-SM04
Dimensions
27
25
32 dia.
7
12
22.7
38
(8.2)
Four, M4 mounting
holes with a depth of 4.0 mm
34
740
30
40
30
Four, M4 mounting
holes with a depth
of 4.0 mm
1"-32UNF
(C MOUNT)
25
16.8
12 22.7
Four, M4 mounting holes
with a depth of 4.0 mm
13 19
9.5
Two, M4 mounting
holes with a depth
of 5.5 mm
1/4" 20UNC with
a depth of 5.5 mm
11.1
(20)
(7.4)
16.8
(Unit: mm)
Four, M4 mounting holes
with a depth of 4.0 mm
16.8
27
25
32 dia.
9.5
14.5
22.7
40.5 (8.2)
Four, M4 mounting
holes with a depth
of 4.0 mm
30
30
40
407
34
1"-32UNF
(C MOUNT)
Four, M4 mounting holes
with a depth of 4.0 mm
25
14.5 22.7
Two, M4 mounting
holes with a depth
of 5.5 mm
9.5
19
1/4" 20UNC with
a depth of 5.5 mm
15.5
22.2
(20)
(7.4)
16.8
(Unit: mm)
