3 Configuration
Vision System FH/FZ5 series Hardware Setup Manual (Z366)
3-2 Camera
3
3-2-3 Digital CCD/CMOS Cameras: FZ-S Camera Series
 5 Megapixels Camera: FZ-S5M3/-SC5M3
Additional Information
We have the 2D CAD data or 3D CAD data.
You can download CAD data from www.fa.omron.co.jp.
(Unit: mm)
Four-R2.5
35
36 dia.
1“-32UNC-2A(C mount)
34
10.5
40.7
14.5±0.05
15.5±0.05
17.69±0.05
22.7
(R1)
2
Mounting holes with a
depth of 2.5 mm (4 directions)
+0.01
0
Mounting Holes
2-4.5 dia.
(1)
35
2.3
15±0.05
16.8±0.05
25±0.05
30 dia.
7
19±0.1
2 dia. mounting holes with a
depth of 2.5 mm (4 directions)
Four M4 mounting holes
with a depth of 4 mm (4 directions)
15.5
9.5
9.5
31.7
Two, M4 mounting
holes with a depth
of 5.5 mm
1/4” 20UNC with a
depth of 5.5 mm
10
