Omron SYSMAC NX series User Manual

Setting
name
Description
De-
fault
val-
ue
Setting
range
Unit
Index
number
(hex)
Subin-
dex
number
(hex)
Update
timing
Refer-
ence
Ch1 Filter 1
Moving Aver-
age Count
Set the moving average
count for the moving aver-
age filter 1 for analog input
signals.
Set this parameter to 0
to
disable the moving average
filter 1.
0 0 to 4096 times 5007 01 Immedi-
ately
8-5 Digi-
tal Filter-
ing on
page
8 - 18
Ch2 Filter 1
Moving Aver-
age Count
02
Ch3 Filter 1
Moving Aver-
age Count
03
Ch4 Filter 1
Moving Aver-
age Count
04
Ch1 Filter 2
Moving Aver-
age Count
Set the moving average
count for the moving aver-
age filter 2 for analog input
signals.
Set this parameter to
0
to
disable the moving average
filter 2.
0 0 to 4096 times 5008 01 Immedi-
ately
8-5 Digi-
tal Filter-
ing on
page
8 - 18
Ch2 Filter 2
Moving Aver-
age Count
02
Ch3 Filter 2
Moving Aver-
age Count
03
Ch4 Filter 2
Moving Aver-
age Count
04
Ch1 Input
Filter Value
Setting
Set the filter time for trigger
input signals.
*3
4
0, or 3 to 9
*3
---
5009
01 Immedi-
ately
8-11 In-
put Filter
on page
8 - 48
Ch2 Input
Filter Value
Setting
02
Ch3 Input
Filter Value
Setting
03
Ch4 Input
Filter Value
Setting
04
*1.
The meanings of the set values for Ch£ Range Setting are as follows.
Set value Meaning
0 -10 to 10 V
1 -5 to 5 V
2 0 to 10 V
3 0 to 5 V
4 1 to 5 V
5 0 to 20 mA
6 4 to 20 mA
*2.
The meanings of the set values for Ch£ Number of Samplings Setting are as follows.
7 I/O Data and List of Settings
7 - 22
NX-series Analog I/O Units User’s Manual for High-speed Analog Input Units (W592)
