Event name Gives the name of the error. Event code Gives the code of the error.
Meaning Gives a short description of the error.
Source Gives the source of the error. Source details Gives details
on the source
of the error
.
Detection tim-
ing
Tells when the
error is detect-
ed.
Error attrib-
utes
Level T
ells the level of influence on
control.
*1
Log category Tells which log the error is saved
in.
*2
Recovery
Gives the recovery method.
*3
Effects User program Tells what will
happen to exe-
cution of the
user program.
*4
Operation Provides special information on the operation that
results from the error
.
Indicators Gives the status of the built-in EtherNet/IP port and built-in EtherCAT port indicators. Indicator status is
given only for errors in the EtherCAT Master Function Module and the EtherNet/IP Function Module.
System-de-
fined varia-
bles
Variable Data type Name
Lists the variable names, data types, and meanings for system-defined variables that provide direct error
notification, that are directly affected by the error, or that contain settings that cause the error
.
Cause and
correction
Assumed cause Correction Prevention
Lists the possible causes, corrections, and preventive measures for the error.
Attached in-
formation
This is the attached information that is displayed by the Support Software or an HMI.
*5
,
*6
Precautions/
Remarks
Provides precautions, restrictions, and supplemental information. If the user can set the event level, the
event levels that can be set, the recovery method, operational information, and other information are al-
so provided.
*1. One of the following:
• Major fault: Major fault level
• Partial fault: Partial fault level
• Minor fault: Minor fault level
• Observation
• Information
*2. One of the following:
• System: System event log
• Access: Access event log
*3. One of the following:
• Automatic recovery: Normal status is restored automatically when the cause of the error is removed.
• Error reset: Normal status is restored when the error is reset after the cause of the error is removed.
• Cycle the power supply: Normal status is restored when the power supply to the Controller is turned OFF
and then back ON after the cause of the error is removed.
• Controller reset: Normal status is restored when the Controller is reset after the cause of the error is re-
moved.
• Depends on cause: The recovery method depends on the cause of the error
.
*4. One of the following:
• Continues: Execution of the user program will continue.
• Stops: Execution of the user program stops.
• Starts: Execution of the user program starts.
*5.
“System information” indicates internal system information that is used by OMRON.
*6. Refer to the appendices of the troubleshooting manual for the connected CPU Unit or Industrial PC for the
applicable range of the HMI T
roubleshooter.
9 Troubleshooting
9 - 13
NX-series Analog I/O Units User’s Manual for High-speed Analog Input Units (W592)
9-3 Checking for Errors and Troubleshooting on the Support Software
9
9-3-4 Meaning of Error
