Variable name
Data
type
Initial
value
AT Retain
Con-
stant
Network
publish
Description
Ch1_Input_Data AR-
RAY[0..9
9] OF
REAL
--- ---
--- --- Do not
publish.
Ch1 Input Data

Internal Variables
Variable name Data type
Initial val-
ue
AT
Re-
tain
Constant Description
I_O_Data_is_Valid BOOL FALSE --- --- --- NX Unit I/O Data Com-
munications Enabled
Ch1_Arrange-
ment_is_Success
BOOL FALSE --- --- --- Ch1 Join Successful
Enable_OUT
*1
BOOL FALSE --- --- --- ---
*1. This variable is used only in ST programming.
Ladder Programming
NXBus_N2_
NX_Unit_
I_O_Data_
Active_Status
NX Unit
I/O Data Active
NXBus_N2_
NX_Unit_
Error_Status
NX Unit Error
I_O_Data_is_Valid
NX Unit
I/O Data
Communications
Enabled
DeviceVariableToArray_100
N2_Ch1_Analog_Input_Value_1_10
N2_Ch1_Analog_Input_Value_11_20
N2_Ch1_Analog_Input_Value_21_30
N2_Ch1_Analog_Input_Value_31_40
N2_Ch1_Analog_Input_Value_41_50
N2_Ch1_Analog_Input_Value_51_60
N2_Ch1_Analog_Input_Value_61_70
N2_Ch1_Analog_Input_Value_71_80
N2_Ch1_Analog_Input_Value_81_90
N2_Ch1_Analog_Input_Value_91_100
UINT#0
N2_Ch1_Number_of_Samplings
Ch1_Input_Data
\\OmronLib\NX_HAD\Device
VariableToArray_100
ENO
NextPos
DataArray
Input01
Input02
Input03
Input04
Input05
Input06
Input07
Input08
Input09
Input10
StartPos
InputSize
I_O_Data_is_Valid
NX Unit
I/O Data
Communications
Enabled
DataArray
Ch1_Input_Data
Ch1_Arrangement_is
_Success
Ch1 Join
Successful
EN
ST Programming
//********************************************************
// DeviceVariableToArray_100
Appendices
A - 16
NX-series Analog I/O Units User’s Manual for High-speed Analog Input Units (W592)
