Variable name Data type
Initial
value
AT
Re-
tain
Con-
stant
Network
publish
Description
N2_Ch1_Ana-
log_Input_Val-
ue_21_30
ARRAY[0..9] OF
INT
---
--- --- --- Do not
publish.
Ch1 Analog Input
Value
21-30
N2_Ch1_Ana-
log_Input_Val-
ue_31_40
ARRAY[0..9] OF
INT
---
--- --- --- Do not
publish.
Ch1 Analog Input
Value
31-40
N2_Ch1_Ana-
log_Input_Val-
ue_41_50
ARRAY[0..9] OF
INT
---
--- --- --- Do not
publish.
Ch1 Analog Input
Value
41-50
N2_Ch1_Ana-
log_Input_Val-
ue_51_60
ARRAY[0..9] OF
INT
---
--- --- --- Do not
publish.
Ch1 Analog Input
Value
51-60
N2_Ch1_Ana-
log_Input_Val-
ue_61_70
ARRAY[0..9] OF
INT
---
--- --- --- Do not
publish.
Ch1 Analog Input
Value
61-70
N2_Ch1_Ana-
log_Input_Val-
ue_71_80
ARRAY[0..9] OF
INT
---
--- --- --- Do not
publish.
Ch1 Analog Input
Value
71-80
N2_Ch1_Ana-
log_Input_Val-
ue_81_90
ARRAY[0..9] OF
INT
---
--- --- --- Do not
publish.
Ch1 Analog Input
Value
81-90
N2_Ch1_Ana-
log_Input_Val-
ue_91_100
ARRAY[0..9] OF
INT
---
--- --- --- Do not
publish.
Ch1 Analog Input
Value
91-100
Ch1_Input_Data ARRAY[0..99] OF
REAL
--- --- --- --- Do not
publish.
Ch1 Input Data
Ch1_Log_Data ARRAY[0..11999]
OF OmronLib\Da-
taRecorder\sLog-
Data
--- --- --- --- Do not
publish.
Ch1 Log Data
Ch1_Data_Buf ARRAY[0..11999]
OF OmronLib\Da-
taRecorder\sLog-
Data
--- --- --- --- Do not
publish.
Ch1 Input Buffer
Ch1_Rec_Info OmronLib\Data-
Recorder\sRecor-
dInfo
--- --- --- --- Do not
publish.
Ch1 Record Infor-
mation
Rec_is_End BOOL FALSE --- --- --- Do not
publish.
Recording Ended

Internal Variables
Variable name Data type
Initial val-
ue
AT
Re-
tain
Constant Description
I_O_Data_is_Valid BOOL FALSE --- --- --- NX Unit I/O Data Com-
munications Enabled
Ch1_Arrange-
ment_is_Success
BOOL FALSE --- --- --- Ch1 Join Successful
Enable_OUT
*1
BOOL FALSE --- --- --- ---
Appendices
A - 28
NX-series Analog I/O Units User’s Manual for High-speed Analog Input Units (W592)
