Variable name Data type
Initial val-
ue
AT
Re-
tain
Constant Description
DataRecorder_instance OmronLib
\DataRe-
corder\Da-
taRecor-
der
--- --- --- --- Data Recorder
Start BOOL FALSE --- --- --- Start
Rec_is_Start BOOL FALSE --- --- --- Recording Started
Trig_Rdy BOOL FALSE --- --- --- Trigger Input Ready
Ch1_Trig_Input BOOL FALSE --- --- --- Ch1 Trigger Input
Ch1_Rec_End BOOL FALSE --- --- --- Ch1 Recording Ended
Enable
*1
BOOL FALSE --- --- --- ---
LogDataToCSV_in-
stance
OmronLib
\DataRe-
corder
\LogData-
T
oCSV
--- ---
--- --- Write Log Data to CSV
File
CSV_Output_is_Start BOOL FALSE --- --- --- CSV Output Started
CSV_Output_is_Done BOOL FALSE --- --- --- CSV Output Done
Execute
*1
BOOL FALSE --- --- --- ---
Done
*1
BOOL FALSE --- --- --- ---
*1. This variable is used only in ST programming.
Ladder Programming

Programming Examples That Use DeviceVariableToArray_100 and DataRe-
corder
The following shows programming examples that use DeviceVariableToArray_100 (Join Device
Output Data) and DataRecorder (Data Recorder). Assign the programs to the priority-4 primary pe-
riodic task.
Appendices
A - 29
NX-series Analog I/O Units User’s Manual for High-speed Analog Input Units (W592)
A-4 Digital Filter Design with the Library
A
A-4-3 Programming Example
