Omron SYSMAC NX series User Manual

Index
(hex)
Subindex
(hex)
Object name
Default
value
Data range Unit
Data
type
Ac-
ces
s
I/O allo-
cation
Data
attrib-
ute
6003 --- Ch3 Input Data --- --- --- --- --- --- ---
00 Number of Entries 67 hex 67 hex --- USINT RO Not pos-
sible
---
01 Ch3 Status 0000 hex 0000 to
0xFFFF hex
--- WORD RO Possible ---
02 Ch3 Trigger Input Time
Stamp
0 0000000000
000000 to
FFFFFFFFF
FFFFFFF
hex
ns ULINT RO Possible ---
03 Ch3 Number of Samplings 1 1, 2, 4, 5,
8, 10, 20,
25, 40,
50, 80,
100, 125,
200, 250,
400, 500,
625, or
1000
--- UINT RO Possible ---
04 Ch3 Analog Input Value
1-10
0 --- --- AR-
RA
Y[0..9]
OF INT
RO Possible
---
05 Ch3 Analog Input Value
11-20
0 --- ---
AR-
RAY[0..9]
OF INT
RO Possible ---
: : : : : : : : :
67 Ch3 Analog Input Value
991-1000
0 --- --- AR-
RAY[0..9]
OF INT
RO Possible
---
• Refer to the relevant data in 7-1-2 Data Details on page 7 - 6 for details on data.
Appendices
A - 43
NX-series Analog I/O Units User’s Manual for High-speed Analog Input Units (W592)
A-5 List of NX Objects
A
A-5-3 Objects That Accept I/O Allocations
