Omron SYSMAC NX series User Manual

Wiring Examples for the NX-HAD401

Wiring Example 1 (Analog input range: Voltage)
24 VDC
A1 B1
A8 B8
IOV
IOG
IOV
IOG
IOV
IOG
IOV
IOG
A1
B1 C1 D1
A8 B8 C8 D8
IN1
IN2
IN3
IN4
NC
NC
NC
NC
SHT1+
SHT2+
SHT3+
SHT4+
Input1+
Input2+
IOV2 IOG2
SHT2- Input2-
IOV1
IOG1
SHT1- Input1-
Input3+
IOV3 IOG3
SHT3- Input3-
Input4+
IOV4 IOG4 SHT4- Input4-
Additional I/O
Power Supply
Unit
*1
Use a two-conductor shielded
twisted-pair cable. Do not ground
the shield.
High-speed Analog Input Unit
NX-HAD401
Two-wire sensor
Three-wire sensor
Output device
Input+
Input-
*1. Besides the Additional I/O Power Supply Unit, some other Units can supply I/O power to the NX bus. For
example, you can use a Connected Communications Coupler Unit. If you use this Unit to supply I/O power
to the High-speed Analog Input Units, the Additional I/O Power Supply Unit is unnecessary. The Additional
I/O Power Supply Unit is also unnecessary if you do not use the trigger inputs of the High-speed Analog
Input Units.

Wiring Example 2 (Analog input range: Current)
24 VDC
A1 B1
A8 B8
IOV
IOG
IOV
IOG
IOV
IOG
IOV
IOG
A1 B1 C1 D1
A8 B8 C8 D8
IN1
IN2
IN3
IN4
NC
NC
NC
NC
SHT1+
SHT2+
SHT3+
SHT4+
Input1+
Input2+
IOV2 IOG2 SHT2- Input2-
IOV1 IOG1
SHT1- Input1-
Input3+
IOV3 IOG3 SHT3- Input3-
Input4+
IOV4 IOG4 SHT4- Input4-
Additional I/O
Power Supply
Unit
*1
Use a two-conductor shielded
twisted-pair cable. Do not
ground the shield.
To use current input,
connect SHT*+ and SHT*- with a
short-circuit cable.
*2
High-speed Analog Input Unit
NX-HAD401
Two-wire sensor
Three-wire sensor
Output device
Input+
Input-
*1. Besides the Additional I/O Power Supply Unit, some other Units can supply I/O power to the NX bus. For
example, you can use a Connected Communications Coupler Unit. If you use this Unit to supply I/O power
to the High-speed Analog Input Units, the Additional I/O Power Supply Unit is unnecessary. The Additional
4 Installation and Wiring
4 - 23
NX-series Analog I/O Units User’s Manual for High-speed Analog Input Units (W592)
4-4 Wiring External Devices
4
4-4-2 Wiring Examples
