Omron V430-F Series User Manual For Communication Settings

Outputs the total number of No Reads.
・Trigger Counter
Outputs the total number of executed Triggers.
・Matchcode Counter
Outputs one of the following.
(1) Total number of matches to the Master Symbol (When Matchcode: Enabled)
(2) Total number of Good Reads (When Matchcode: Enabled)
・Mismatch Counter
Outputs the total number of Mismatches (not matching Master Symbol).
• Read Cycle Report
Read Cycle Report Size (Bytes)
Capture Time 2
Total Decode Time 2
Total Read Cycle Time 2
Reserved 2
・Capture Time
The time required for image capture. (milliseconds)
・Total Decode Time
The time required for decoding a symbol. (milliseconds)
・Total Read Cycle Time
The total time taken to read symbols. This encompasses the total time of image capture, decoding
and overhead. (milliseconds)
• Decode Cycle Report
Outputs symbol information.
Symbol Information Size (Bytes)
Decode Location Top 2
Decode Location Left 2
Decode Location Height 2
Decode Location Width 2
Code Type 4
Pixels per Element 4
・Decode Location Top
The upper left Y coordinate of the Symbol Detection Region. (pixels)
・Decode Location Left
The upper left Y coordinate of the Symbol Detection Region. (pixels)
・Decode Location Height
The Y size of the Symbol Detection Region. (pixels)
・Decode Location Width
The X size of the Symbol Detection Region. (pixels)
・Code Type
A bit indicating the Symbol Type of the decoded symbol is output.
Bit State
0 Aztec Code
Appendices
A - 12
V430-F Series Autofocus Multicode Reader User Manual for Communication Settings
