Category Command Description
Response Data Example
(For Read string ABCDE.)
Device Con-
trol
<L1> Parallel OUTPUT 1 Signal turns ON. None
<L2> Parallel OUTPUT 2 Signal turns ON. None
<L3> Parallel OUTPUT 3 Signal turns ON. None
<l1> Turn ON the target pattern (blue LED). None
<l0> Turn OFF the target pattern (blue LED). None
<I> Disables Read Cycle. While Read Cycle is
Disabled, it cannot accept a trigger
.
None
<H> Enables Read Cycle. None
Counters and
Counter re-
sets
<q> Gets the number of No Reads in the Read Cy-
cle. The Response data output is q/ followed
by a 9 digit value for the number of No Read
<q/000000005>
<q0> Clears the number of No Reads in the Read
Cycle.
None
<$> Gets the Mismatch Count. The Response data
output is $/ followed by a 9 digit value for the
number of Mismatch.
<$/000000002>
<$0> Clears the Mismatch Count. None
<N> Gets the number of No Reads. The Response
data output is N/ followed by a 9 digit value for
the number of No Reads
<N/000000005>
<O> Clears the Mismatch Count. None
<T> Gets the Trigger Input Count. The Response
data output is T/ followed by a 9 digit value for
the number of T
riggers.
<T/000000010>
<U> Clears the T
rigger Input Count. None
<V> Gets the Match Count when the Matchcode
function is used. The Response data output is
V/ followed by a 9 digit value for the number
of Matched strings.
<V/000000010>
<W> Clears the Match Count. None
<X> Gets the Mismatch Count when the
Matchcode function is used. The Response
data output is X/ followed by a 9 digit value
for the number of Mismatched strings.
<Y> Clears the Mismatch Count. None
