4300 CLAMP
-
ON ULTRASONIC FLOW METER
ONICON Incorporated 727.447.6140 Page 23 onicon.com
When installing the transducer, do not allow
the bottom face to touch the pipe surface
until it is fully inserted to the bracket
compound down the center of the transducer
Too little grease
Compound
Clamp
Pipe
Sensor
Sensor
Compound
5. Apply a small amount of coupling compound to the transducers. A packet of acoustic coupling compound was supplied
with the transducers. Contact ONICON if you need more compound.
Conduit Adapter
6.
butts against the mounting bracket. The clamping bracket can be retracted such that the transducer can be directly over
7.
installation easier.
3.3.3.2 Two (2) or Four (4) Cross Mounting Installation for 20 Series Transducers (Continued)
To Next Page
