5.
the pipe, place a mark at the center of the bottom of the bracket as shown below. Next, mark along the edge of the
bracket as indicated in the drawing below.
Place mark at center
of bracket roller
of bracket
6. Remove the bracket from the alignment and spacer tool and then remove the alignment and spacer tool from the
down the center of the pipe intersecting the mark made at the center of the tapered roller and the line drawn against
the edge of the bracket as shown below.
around the pipe and mark
at the overlapping edge
50%
50%
Overlap edge mark
7.
end overlaps the other. Ensure that it is snug around the pipe and mark along the overlapping edge.
8.
edge and the mark at the overlap or fold the guide from the overlap edge to overlap mark and draw a line at the fold
or halfway point.
3.3.4.3 One (1) Cross Mounting Installation for 30 Series Transducers (Continued)
Alignment and spacer tool
To Next Page
