4.5 PROGRAMMING MENU PAGES (Continued)
Relay Parameters Menu Page
The relay parameters page is where changes can be made to the pulse outputs
available with the F-4300.
Relay –
Function –
Choices:
On – Pulse is always engaged
O – Pulse is always disengaged
Pulse –
Flow –
alarm comes ON, and when the alarm will turn OFF again.
Examples:
Direction
Data Logging Menu Page
what is being logged, how often it is being logged, and the date settings.
points.
--Relay Parameters--
Relay 1
Function Flow
On 1000 USG
Off 0.000 USG
--Data Logging-------
Log Site ID 01
Mode Flow
File Format .LG2
Date Mar. 20/2020
Time 12:28:41
Interval 30sec
Data Log Logging
IMPORTANT NOTE
The logger must be congured in a specic order in order to function correctly:
1. Set the Log Site ID, Mode, File Format, Date, Time, and Interval to the desired option.
2. Under Data Log, select “Delete”
3. Under Data Log, select “Start”
4. Deploying the logger in any other order will compromise the settings you’ve chosen.
To Next Page
