F
-
4300 CLAMP
-
ON ULTRASONIC FLOW METER
ONICON Incorporated 727.447.6140 Page 53 onicon.com
--Communication-----
Protocol Modbus
Address 001
BPS 9600
Parity Even
Stop Bits 1
Communications Menu Page
The communications menu provides the means to select the serial output of the
meter, and the addressing and communication speed.
Protocol –
DevID –
which must be unique for the device across the whole BACnet network.
Range: 0-4,194,302.
MAC Address – Only available if BACnet was the selected Protocol. This is the
Range: 0-127 for master devices, 128-254 for slave devices.
BPS –
Options: 9600, 19200, 38400, 76800.
4.5 PROGRAMMING MENU PAGES (Continued)
Special Functions Menu Page
Language –
Analog Out –
Backlight – Raise or lower the brightness of the display backlight.
Reset Totalizer –
pressing to indicate the action was accepted.
Neg. Totals –
a negative value if negative totals are greater than positive totals.
Rev.FLow -
Capture Par - This function captures the programming parameters in the meter.
Capture WF - This function captures the ultrasonic signal so that it can be
evaluated by ONICON. Contact ONICON for the instructions.
Restore Defaults –
ONICON performed at the factory before the meter was shipped.
New Password – This function allows a new password to be set. This password
need to return to the programming menu at a later date.
--Special Functions-
Language English
Analog Out 4-20mA
Backlight High
Reset Totalizer NO
Neg. Totals NO
Rev. Flow OFF
Capture Par NO
Capture WF NO
Restore Defaults NO
New Password 0000
To Next Page
