Table 1-30 (Cont.) Low-voltage 24 kVA Three Phase PDUs for North America,
South America, Japan and Taiwan (2 PDUs per Rack)
Option Requirement, per PDU
Outlets 42 x C13; 6 x C19
Outlet groups 6
Group protection (UL489 2-pole circuit
breaker)
20A
Data center receptacle IEC309-3P4W-IP67 60A 250VAC 3ph
(Hubbell equivalent is HBL460R9W)
The following are needed to connect an Oracle Exadata system to a low-voltage three-
phase power source:
• 4 power cords for two PDUs
• 4 receptacles to connect the PDUs
Table 1-31 (page 1-41) lists the PDU requirements for high-voltage 24 kVA three
phase PDUs. The following specifications are per PDU.
Table 1-31 High-voltage 24 kVA Three Phase PDUs for Europe, the Middle East
and Africa (EMEA), and Asia Pacific (APAC), except for Japan and Taiwan (2
PDUs per Rack)
Option Requirement, per PDU
Voltage 220/380 - 240/415 VAC 3-phase
Frequency 50/60 Hz
Current 18.1 A maximum per phase
Power rating 25 kVA
Output current 108.6A (6 x 18.1 A)
Outlets 42 x C13; 6 x C19
Outlet groups 6
Group protection (UL489 1-pole circuit
breaker)
20A
Data center receptacle IEC309-4P5W-IP44 32A 400VAC 3ph
(Hubbell equivalent is HBL532R6W)
The following are needed to connect an Oracle Exadata system to a high-voltage
three-phase power source:
• 4 power cords for two PDUs
• 4 receptacles to connect the PDUs
Table 1-32 (page 1-42) lists the requirements for 37 kVA low-voltage three-phase
PDUs for Oracle Exadata Database Machine X6-8, X5-8, and X4-8 with more than four
database servers. There are two PDUs per rack. The following specifications are per
PDU.
Chapter 1
Electrical Power Requirements
1-41
