Table 1-29 (Cont.) High-voltage 22 kVA Single Phase PDUs for Europe, the
Middle East and Africa (EMEA), and Asia Pacific (APAC), except for Japan and
Taiwan (2 PDUs per Rack)
Option Requirement, per PDU
Frequency 50/60 Hz
Current 32 A maximum per input
Power rating 22 kVA
Output current 96 A (3 x 32 A)
Outlets 42 x C13; 6 x C19
Outlet groups 6
Group protection (UL489 1-pole circuit
breaker)
20A
Data center receptacle IEC309-2P3W-IP44 32A 250VAC (Hubbell
equivalent is HBL332R6W)
Note:
The high-voltage 15kVA single phase PDU is no longer available. The high-
voltage 22kVA is a compatible replacement with the same receptacle and
breaker requirements
The following are needed to connect an Oracle Exadata system to a high-voltage one-
phase power source:
• 6 power cords for two PDUs, 25 amperes at 220/380 - 240/415 VAC 1-phase
voltage
• 6 receptacles to connect the PDUs to 2 IEC 60309 32A 3-pin 250VAC IP44 data
center receptacles, and requires 22 kVA, 1-phase
Figure 1-3 (page 1-37) shows the high-voltage single phase PDU power connector for
EMEA, and APAC, except for Japan and Taiwan.
Table 1-30 (page 1-40) lists the requirements for low-voltage 24 kVA three phase
PDUs. There are two PDUs per rack. The following specifications are per PDU.
Table 1-30 Low-voltage 24 kVA Three Phase PDUs for North America, South
America, Japan and Taiwan (2 PDUs per Rack)
Option Requirement, per PDU
Voltage 200 - 208 VAC 3-phase
Frequency 50/60 Hz
Current 34.6 A maximum per phase
Power rating 25 kVA
Output current 120 A (6 x 20 A)
Chapter 1
Electrical Power Requirements
1-40
