PUMA T2
Technical Handbook
Troubleshooting
P/N: 779-0306/01
Revision 03
OTE Proprietary information
Page 81
The troubleshooting procedures are shown in the flow diagrams whose symbols
are described in Tab. 7.3.
Tab. 7.3: Description of the symbols used in the troubleshooting flow diagrams
Symbol Meaning
Stands for the beginning or the end of the flow diagram. The symptom
of the possible fault is described inside the symbol.
Stands for the action to be carried out. This action is described inside
the symbol itself.
Stands for a decision to be made. The question that must be answered
is shown inside the symbol.
Stands for the term of the search.
Fig. 7.9: It‘s not possible to control the volume of the speaker
It‘s not possible to
control the volume
of the speaker
Send the radio to the
OTE assistance
centre
END SEARCH
To Next Page
