PUMA T2
Technical Handbook
General information
P/N: 779-0306/01
Revision 03
OTE Proprietary information
Page 1
1. GENERAL INFORMATION
1.1 INTRODUCTION
This technical manual contains the description of the PUMA T2 hand-portable
radio unit, a mobile form of radio communications equipment operating in a
frequency band that depends on the PUMA T2 versions (400 MHz, 430 MHz, 470
MHz, 870 MHz). The PUMA T2 transceiver is a frequency synthetized equipment
controlled by a microprocessor and designed for voice and data
reception/transmission TETRA communication system.
The information and descriptions given in this manual are related to product
development. Therefore they can be changed according to the product release.
The manual is divided into the following sections:
Section 1: General information
The equipment’s purpose, structure, functions, main technical data, safety
recommendations and TETRA network overview are described in this section.
Section 2: Technical description
The functional description of each assembly present in the equipment is contained
in this section.
Section 3: Installation
The equipment’s installation and wiring procedures are described in this section.
Section 4: Setting up
The procedures for inspection and setting up of the equipment are described in this
section.
Section 5: Disposal
Information on the disposal of equipment parts is given in this section.
Section 6: Preventive maintenance
This section gives information on the preventive maintenance procedures of the
equipment.
Section 7: Troubleshooting
This section gives information on the troubleshooting procedures of the equipment.
Section 8: Corrective maintenance
This section gives information on the corrective maintenance procedures of the
equipment.
