Equipment
Portable radio PUMA T2
Operation
Radio body replacement
Required tools
-
None
Consumable materials
-
Radio body
Form number
CM-03
Page
1/2
Periodicit
y
Maintenance level
Not a
pp
licable
I
PROCEDURE
Read all the safety recommendations before proceeding.
• Extract the battery (1, fig. 1) as explained in the CM-02 form.
• Extract the antenna (2) as explained in the CM-01 form.
• Replace the radio body (3).
• Screw the antenna as explained in the CM-01 form.
• Insert the battery again as explained in the CM-02 form.
