PUMA T2
Technical Handbook
Corrective Maintenance
P/N: 779-0306/01
Revision 03
OTE Proprietary information
Page 99
Equipment
Portable radio PUMA T2
Operation
Connector cover replacement
Required tools
-
None
Consumable materials
- Side connector cover
- Upper connector cover
Form number
CM-04
Page
1/2
Periodicit
Maintenance level
Not a
licable
PROCEDURE
Read all the safety recommendations before proceeding.
• To replace the side connector cover we have to unscrew the antenna, as explained in the
CM-01 form, replace the connector, screw the antenna back to the radio body and block
the ring as shown in fig. 1.
• To replace the upper connector cover, it is sufficient to take the new connector cover and
before closing we have to insert the ring to lock it as shown in fig. 2.
