1. When using the MEWTOCOL master function in TCP
Set as follows for each unit using Configurator WD.
IP address setting
Communication setting
Option setting
Master unit
IP address: 192.168.1.5
Netmask: 255.255.255.0
Gateway: 192.168.1.1
Communication protocol: TCP
Action mode: Client connection
Baud rate: 115200 bps
Communication mode:
Computer link
Destination IP address:
192.168.1.11
Destination port No.: 9094
Source port No.: 0
Timeout: 0
Retry time: 15
Destination unit No.
and IP address is
specified: On
Target IP address
for unit No.:
No.1: 192.168.1.11
No.2: 192.168.1.12
Slave unit 1
IP address: 192.168.1.11
Netmask: 255.255.255.0
Gateway: 192.168.1.1
Communication protocol: TCP
Action mode: Server connection
Baud rate: 115200 bps
Communication mode:
Computer link
Source port No.: 9094
Timeout: 0
Not necessary.
Slave unit 2
IP address: 192.168.1.2
Netmask: 255.255.255.0
Gateway: 192.168.1.1
Communication protocol: TCP
Action mode: Server connection
Baud rate: 115200 bps
Communication mode:
Computer link
Source port No.: 9094
Timeout: 0
Not necessary.
2. When using the MEWTOCOL master function in UDP, UNICAST communication
Set as follows for each unit using Configurator WD.
IP address setting
Communication setting
Option setting
Master unit
IP address: 192.168.1.5
Netmask: 255.255.255.0
Gateway: 192.168.1.1
Communication protocol: UDP
Action mode: Client connection
Baud rate: 115200 bps
Communication mode:
Computer link
Send type: UNICAST
Destination IP address:
192.168.1.11
Destination port No.: 9094
Source port No.: 0
Destination unit No.
and IP address is
specified: On
Target IP address for
unit No.:
No.1: 192.168.1.11
No.2: 192.168.1.12
Slave unit 1 IP address: 192.168.1.11
Netmask: 255.255.255.0
Gateway: 192.168.1.1
Communication protocol: UDP
Action mode: Server connection
Baud rate: 115200 bps
Communication mode:
Computer link
Send type: UNICAST
Source port No.: 9094
Not necessary.
Slave unit 2
IP address: 192.168.1.2
Netmask: 255.255.255.0
Gateway: 192.168.1.1
Communication protocol: UDP
Action mode: Server connection
Baud rate: 115200 bps
Communication mode:
Computer link
Send type: UNICAST
Source port No.: 9094
Not necessary.
